GLC-GE-DR-LX-FL Cisco GLC-GE-DR-LX-FL Compatible 100/1000Base-LX SFP 1310nm 10km EXT Duplex LC SMF Optical Transceiver Module

$9.99

Free continental US shipping on orders over $99 Details

Loading...

Need a larger quantity? Request a quote

Questions? Call (888) 874-7574

Quick Specs

Form Factor
SFP
Rate Category
100/1000Base
Rate Category
1000Base
Rate Category
100Base
TX Wavelength
1310nm
Interface Type
LX
Reach
10km
Connector
Dual-LC
Cable Type
SMF
DDM
No
Temperature
(EXT) -5°C to 85°C
TAA
No

Overview

The dual-rate GLC-GE-DR-LX-FL 100Base/1000Base 10Km SFP is interoperable with the IEEE 100BASE-LX and 1000BASE-LX/LH standards. The GLC-GE-DR-LX-FL also supports Digital Optical Monitoring (DOM) functions according to the industry-standard SFF-8472 Multisource Agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.  The GLC-GE-DR-LX-FL can interoperate with other 100Base SFPs/interfaces as long as those are based on 100BASE-LX10 standard. A 5dB attenuator is needed on the path of dual-rate SFP Tx and 100BASE-LX10 interface Rx. No attenuator is needed on the other fiber strand.  The GLC-GE-DR-LX-FL can interoperate with other 1000Base SFPs/interfaces as long as those are based on 1000BASE-LX/LH standard. No attenuator is needed in any fiber strand.

Cisco 8000 Routers2
  • 84-MPA-2H12Z-M
  • 8011-4G24Y4H-I
8000 Secure Routers11
  • C8231-E-G2
  • C8231-G2
  • C8235-E-G2
  • C8235-G2
  • C8355-G2
  • C8375-E-G2
  • C8455-G2
  • C8475-G2
  • C8550-G2
  • C8570-G2
  • C8650-G2
Catalyst 8000 Edge4
  • C-NIM-4X
  • C-NIM-WAN-2X
  • C-NIM-WAN-4S
  • C8500-20X6C
ASR 900 / 901 / 903 / 92013
  • A900-IMA8S
  • A900-IMA8S1Z
  • A900-IMA8Z
  • ASR-920-4SZ
  • ASR-920-8S4Z
  • ASR-920-8S4Z-PD
  • ASR-920-10SZ
  • ASR-920-10SZ-PD
  • ASR-920-12CZ
  • ASR-920-12SZ
  • ASR-920-12SZ-IM
  • ASR-920-24SZ-IM
  • ASR-920-24SZ-M
ASR 900025
  • A9K-4HG-FLEX-X-FC
  • A9K-4HG-FLEX-X-SE
  • A9K-24X10GE-1G-FC
  • A9K-24X10GE-1G-SE
  • A9K-24X10GE-1G-TR
  • A9K-48X10GE-1G-FC
  • A9K-48X10GE-1G-SE
  • A9K-48X10GE-1G-TR
  • A9K-MPA-20X1GE
  • A9K-MPA-20X1GE-FC
  • A9K-RSP440-LT
  • A9K-RSP440-SE
  • A9K-RSP440-TR
  • A9KV-V2-AC
  • A9KV-V2-DC-A
  • A9KV-V2-DC-E
  • A99-4HG-FLEX-X-FC
  • A99-4HG-FLEX-X-SE
  • A99-48X10GE-1G-FC
  • A99-48X10GE-1G-SE
  • A99-48X10GE-1G-TR
  • ASR-9000V-24-A
  • ASR-9000V-AC
  • ASR-9000V-DC-A
  • ASR-9000V-DC-E
NCS 520 / 540 / 56026
  • A900-IMA-8Z-L
  • N540-6Z14S-SYS-D
  • N540-6Z18G-SYS-A
  • N540-6Z18G-SYS-D
  • N540-12Z20G-SYS-A
  • N540-12Z20G-SYS-D
  • N540-24Q2C2DD-SYS
  • N540-24Q8L2DD-SYS
  • N540-24Z8Q2C-SYS
  • N540-28Z4C-SYS-A
  • N540-28Z4C-SYS-D
  • N540-ACC-SYS
  • N540-FH-AGG-SYS
  • N540-FH-CSR-SYS
  • N540X-4Z14G2Q-A
  • N540X-4Z14G2Q-D
  • N540X-6Z18G-SYS-A
  • N540X-6Z18G-SYS-D
  • N540X-8Z16G-SYS-A
  • N540X-8Z16G-SYS-D
  • N540X-12Z16G-SYS-A
  • N540X-12Z16G-SYS-D
  • N540X-16Z4G8Q2C-A
  • N540X-16Z4G8Q2C-D
  • N540X-16Z8Q2C-D
  • N540X-ACC-SYS
NCS 42004
  • NCS4200-1T8LR-PS
  • NCS4200-8T-PS
  • NCS4201-SA
  • NCS4202-SA

Licensing

The following is a list of Finisar Corporation patents Fluxlight has licensed. This licensure recognizes and compensates Finisar for their intellectual property. The GLC-GE-DR-LX-FL , like all Fluxlight optical transceivers, is covered by this license agreement. Therefore, Fluxlight customers can rest assured that all products purchased are fully licensed, and our customers are under no potential liability that may ensue from the use of unlicensed optical transceiver products.

U.S. Patent Numbers: 7,184,668 (System and method of protecting eye safety during operation of a fiber optic transceiver), 7,079,775 (Integrated memory mapped controller circuit for fiber optics transceiver), 6,957,021 (Optical transceiver with memory mapped locations), 7,058,310 (System and method for protecting eye safety during operation of a fiber optic transceiver), 6,952,531 (System and method for protecting eye safety during operation of a fiber optic transceiver), 7,162,160 (System and method for protecting eye safety during operation of a fiber optic transceiver), 7,050,720 (Integrated memory mapped controller circuit for fiber optics transceiver)

Original Equipment Manufacturer (OEM) names may be registered trademarks of the respective OEM, and the OEM has neither authorized nor sponsored the use of its trademark or trade name. All OEM names are used for cross reference/comparative purposes only.

Warranty

This part is covered by our Limited Lifetime Warranty, a 10-year serviceable lifetime, and our 30-Day Money-Back Guarantee. Read the full warranty and return terms.
